BEISSBARTH MLD 815

BEISSBARTH MLD 815 Headlight testing device MLD 815 | with inclinometer Beissbarth MLD 815 - Digital headlight measurement and adjustment Article number: 1 692 104 356 Description Technical Data Accessories German Road Traffic Type-Approval Law StVZO § 29 general-inspection headlight-test directive: MLD 815 can be calibrated according to the legal requirements TÜV certificate in line with StVZO § 50 - TPN 2023-05-2208484: MLD 815 is TÜV-certified by prototype technical release examination in accordance with the directives for testing headlight adjustment/test equipment (German Road Traffic Type-Approval Law StVZO §50 paragraph 5). The alignment (leveling) of the MLD 815 on the testing bay corresponds to the latest requirements. Two-dimensional spirit level for horizontal leveling of the optical box Levelable 3-Wheel base system fitting for all common rail systems Levelable rail system for above and inground installation (3 m) as optional available accessory Digital headlight testing with MLD 815: intelligent, fast and precise Cross- and alignment laser for precise positioning For all light sources (Xenon, Bi-Xenon, LED, Bi-LED, Halogen) and glare-free high-beam systems (Dynamic Light Assist - DLA, Matrix, ILS Ford) All types of vehicles (passenger cars, trucks, motorcycles) All types of headlights (main headlights, fog lamps, auxiliary lamps) CMOS camera for real-time digital image processing Built-in printer Measurement results in real time Comparison between measured and limit values and unambiguous red/green evaluation Precise definition of the cut-off line without disrupting blue fringe Digital LCD colour display (5.7") with 262,000 colours Touch-screen function (operation with gloves is possible) Intuitive and simple user guidance Visual and acoustic signals support the measurement procedure Menu featuring 7 languages Operating panel can be rotated by 180° for different areas of application (e.g. for general inspections or for the adjustment at the workshop) Independent operation thanks to battery - Storage battery Alignment laser: 3 x Mignon AA 1.5 V Measuring height (optical center): 24 - 145 cm Measured values: Horizontal and vertical deviation (pitch angle), intensity, roll angle, yaw angle Digital precision: +/- 1 cm on a 10-meter measuring distance Test results via WLAN with quick and aptly arranged results on the PC Optional: visualization on the workshop computer Displaying of the cut-off line on the PC monitor or TFT screen Data transfer to PC via WLAN User interface simplifies intuitive use Database function Printing and archiving Adjustment of the colour scheme by the user: Light/dark background depending on the lighting conditions Workshop Network Connectivity: Supports Bosch Connected Repair, ASA Network Compatibility is guaranteed Certificate: CE, TÜV, EMC, FCC, FDA Weight 46 kg Operating temperature 5 - 45 °C Electrical connection 100 - 240 V | 50 - 60 Hz Battery voltage (DC) 12 V Height of light center 250 - 1500 mm Measuring range lowest stand/highest stand 600 - -600 mm Light intensity 0 - 150000 cd Illumination (1m) 0 - 150000 / (25m) 0 - 240 lx Storage temperature -25 - 45 °C Version - Digital Packaging length 1810 mm Packaging width 660 mm Packaging height 500 mm Gross weight 66 kg Measuring range low beam left/right 1000 - -1000 mm Measuring range high beam left/right 1000 - -1000 mm Relative humidity storage 20 - 80 % Relative humidity, use 30 - 60 % Radiant power alignment laser 5 mW Operating voltage alignment laser 3 - 5 V (DC) Laser class alignment laser 2 Projection alignment laser 130° x 0,4 mrad Laser diode alignment laser 635 nm Laser class cross laser 2 Projection cross laser 90° x 0,4 mrad Laser diode cross laser 635 nm Radiant power cross laser 5 mW Operating voltage cross laser 3 - 5 V (DC) Integrated inclinometer Yes Rail kit 3 m 1 692 105 080 Extension kit for rail kit | 1.5 m 1 692 105 112 Height-messuring sensor | for MLD 6xx and 8xx 1 692 105 066 Cover for headlight testing devices 1 692 105 079 Alignment kit for alignment on the vehicle center line Ford requirement | for MLD 815 1 692 105 180 PC Software Icperform - Headlight 1 692 105 145 Matrix 2 Upgrade | for MLD 815 1 692 105 269 Ford Matrix | for MLD 815 1 692 105 288 Skoda Function | for MLD 815 1 692 105 289
